Endress+Hauser Levelflex M FMP40 Technische Information Seite 60

60
50 Prozessanschluss:
ACJ 1-1/2" 150lbs RF, 316/316L Flansch ANSI B16.5
ACM 1-1/2" 150lbs, AlloyC22 >316/316L Flansch ANSI B16.5
ADJ 1-1/2" 300lbs RF, 316/316L Flansch ANSI B16.5
ADM 1-1/2" 300lbs, AlloyC22 >316/316L Flansch ANSI B16.5
AEJ 2" 150lbs RF, 316/316L Flansch ANSI B16.5
AEM 2" 150lbs, AlloyC22 >316/316L Flansch ANSI B16.5
AFJ 2" 300lbs RF, 316/316L Flansch ANSI B16.5
AFM 2" 300lbs, AlloyC22 >316/316L Flansch ANSI B16.5
ALJ 3" 150lbs RF, 316/316L Flansch ANSI B16.5
ALM 3" 150lbs, AlloyC22 >316/316L Flansch ANSI B16.5
AMJ 3" 300lbs RF, 316/316L Flansch ANSI B16.5
AMM 3" 300lbs, AlloyC22 >316/316L Flansch ANSI B16.5
APJ 4" 150lbs RF, 316/316L Flansch ANSI B16.5
APM 4" 150lbs, AlloyC22 >316/316L Flansch ANSI B16.5
AQJ 4" 300lbs RF, 316/316L Flansch ANSI B16.5
AQM 4" 300lbs, AlloyC22 >316/316L Flansch ANSI B16.5
AWJ 6" 150lbs RF, 316/316L Flansch ANSI B16.5
AWM 6" 150lbs, AlloyC22 >316/316L Flansch ANSI B16.5
A3J 8" 150lbs RF, 316/316L Flansch ANSI B16.5
CFJ DN40 PN25/40 B1, 316L Flansch EN1092-1 (DIN2527 C)
CFM DN40 PN25/40, AlloyC22 >316L Flansch EN1092-1 (DIN2527)
CGJ DN50 PN25/40 B1, 316L Flansch EN1092-1 (DIN2527 C)
CGM DN50 PN25/40, AlloyC22 >316L Flansch EN1092-1 (DIN2527)
CMJ DN80 PN10/16 B1, 316L Flansch EN1092-1 (DIN2527 C)
CMM DN80 PN10/16, AlloyC22 >316L Flansch EN1092-1 (DIN2527)
CSJ DN80 PN25/40 B1, 316L Flansch EN1092-1 (DIN2527 C)
CSM DN80 PN25/40, AlloyC22 >316L Flansch EN1092-1 (DIN2527)
CQJ DN100 PN10/16 B1, 316L Flansch EN1092-1 (DIN2527 C)
CQM DN100 PN10/16, AlloyC22 >316L Flansch EN1092-1 (DIN2527)
CTJ DN100 PN25/40 B1, 316L Flansch EN1092-1 (DIN2527 C)
CTM DN100 PN25/40, AlloyC22 >316L Flansch EN1092-1 (DIN2527)
CWJ DN150 PN10/16 B1, 316L Flansch EN1092-1 (DIN2527 C)
CWM DN150 PN10/16, AlloyC22 >316L Flansch EN1092-1 (DIN2527)
CXJ DN200 PN16 B1, 316L Flansch EN1092-1 (DIN2527 C)
CRJ Gewinde ISO228 G3/4, 316L
GRJ Gewinde ISO228 G1-1/2, 316L
GRM Gewinde ISO228 G1-1/2, AlloyC22
CNJ Gewinde ANSI NPT3/4, 316L
GNJ Gewinde ANSI NPT1-1/2, 316L
GNM Gewinde ANSI NPT1-1/2, AlloyC22
KDJ 10K 40A RF, 316L Flansch JIS B2220
KDM 10K 40A, AlloyC22 >316L Flansch JIS B2220
KEJ 10K 50A RF, 316L Flansch JIS B2220
KEM 10K 50A, AlloyC22 >316L Flansch JIS B2220
KLJ 10K 80A RF, 316L Flansch JIS B2220
KLM 10K 80A, AlloyC22 >316L Flansch JIS B2220
KPJ 10K 100A RF, 316L Flansch JIS B2220
KPM 10K 100A, AlloyC22 >316L Flansch JIS B2220
YY9 Sonderausführung, TSP-Nr. zu spez.
60 Hilfsenergie; Ausgang:
B
D 2-Leiter; PROFIBUS PA
F
G 4-Leiter 90-250VAC; 4-20mA SIL HART
H 4-Leiter 10.5-32VDC; 4-20mA SIL HART
K 2-Leiter; 4-20mA HART, Trennschicht Messung
Y
70
2-Leiter; 4-20mA SIL HART
2-Leiter; FOUNDATION Fieldbus
Sonderausführung, TSP-Nr. zu spez.
Bedienung:
1 ohne Anzeige, via Kommunikation
2 4-zeilige Anzeige VU331, Hüllkurvendarstellung vor Ort
3 Vorber. für FHX40, getrennte Anzeige (Zubehör)
9 Sonderausführung, TSP-Nr. zu spez.
