OSD MENUS

Speaker C C onfiguration
Assign the size of the speakers in your system (Small, Large or None if
not used).
Speaker D D elay
Set delay for your speakers according to their positions in your room.
This is calculated in milliseconds per metre. Please refer to the
'Surround Sound Setup' section of this manual for more information on
these speaker setup menus.
Level C C alibration
Select to send a test tone signal through individual speakers. Adjust the
output to obtain the best sound. Please refer to the 'Surround Sound
Setup' section of this manual for more information on these speaker
setup menus.
Input S S etup
Assign the audio source inputs to be digital or analog each time they are
selected. Video 3, Tuner, Tape, and 6.1 Direct will always be analog.
Output S S etup
If an external amplifier is connected via the 6.1 Preamp out sockets,
select 'Preamp Out' to mute the internal amplifiers.
Input A A ssign
Assign the Component video and/or digital audio source inputs for Video
1/Video 2.
540R V2.0 AV receiver
OSD S S etup
TV format - Choose PAL (UK/Europe) or NTSC (Canada/USA) depending
on your TV type.
Background - Choose a blue screen or video source as the background
image for the OSD setup menu.
OSD Video - If Video selected for the background, choose the video
source (Composite or S-Video).
Language - Scroll through the available languages for the OSD setup
menu and press the Enter button to select.
Bass/Treble C C onfiguration
Increase/decrease the bass/treble tone control settings.
Sub C C rossover F F requency
Set the frequency at which bass sounds are to be sent to the subwoofer
(range 40Hz - 200Hz).
Software V V ersion
Displays the current loaded software version.
Azur AV receiver 21
