Optical I I n
7
Connect to the digital optical (Toslink) outputs from source equipment.
Optical O O ut
8
Connect to the digital optical (Toslink) input of an external recording
device (eg MD/CDR etc) to record from the selected digital audio source.
Coax I I n
9
Connect to the digital coaxial (SPDIF) outputs from source equipment.
Coax O O ut
10
Connect to the digital coaxial (SPDIF) input of an external recording
device (eg MD/CDR etc) to record from the selected digital audio source.
Control B B us I I n
11
Allows un-modulated commands from multi-room systems or other
components to be received by the 540R V2.0.
Reset
12
Resets all factory default settings. Refer to the 'Reset/Back-up memory'
section of this manual for more information.
Power O O n/Off
13
Switches the unit on and off.
Mains p p ower l l ead
14
Once you have completed all connections, plug the AC power lead into
an appropriate mains socket. The AV receiver is now ready for use.
540R V2.0 AV receiver
Speaker t t erminals
15
Connect to loudspeakers with an impedance of between 4-8 ohms.
6.1 P P reamp O O ut
16
Connect to the 6.1 (or 5.1) channel input terminals of another amplifier
system, separate power amps, subwoofer or active loudspeakers.
6.1 D D irect I I n
17
Connect to the 6.1 (or 5.1) channel output terminals of a DVD player
with built-in surround sound decoding for playing DVD-A or SACD.
Tape
18
Connect the Tape Play sockets to the line output terminals of a Tape
deck, MD player, CD-R etc. Connect the Tape Rec sockets to the line
input terminals of a Tape deck, MD player, CD-R etc.
Audio i i nputs
19
Connect to the audio line output terminals of a source device (eg CD,
DVD player etc).
RS232C
20
For use by an installer/dealer for software updates.
Azur AV receiver 11
