insTallaTiOn

8.1. safety instructions
Danger!
risk of injury from high pressure in the equipment!
• Before loosening the lines and valves, turn off the pressure and
vent the lines.
risk of injury due to electrical shock!
• Before reaching into the device or the equipment,
power supply and secure to prevent reactivation!
• Observe applicable accident prevention and safety regulations
for electrical equipment!
Warning!
risk of injury from improper installation!
• Installation may be carried out by authorized technicians only
and with the appropriate tools!
risk of injury from unintentional activation of the system and
an uncontrolled restart!
• Secure system from unintentional activation.
• Following installation, ensure a controlled restart.
18
switch off the
english
Type 8858
Installation
8.2. fluid installation of the Motor
control Valve Type 8858
Danger!
risk of injury from high pressure in the equipment!
• Before loosening the lines and valves, turn off the pressure and
vent the lines.
risk of scalding by improper connection of the hose
connections!
When detaching the hoses, there is an acute risk of injury.
• Securely connect all hoses to the hose connection nozzles.
The installation of the connection lines must not exert lateral
tensioning forces on the hose connection nozzles of the
motor control valve.
The nozzles and connection lines must be in alignment!
→
Connect the connection lines to the connection nozzles of the
motor control valve according to the circuit function.
The inlets are identified by P and the outlets by A and/or B.
