6.2 Parameters menu

The machine configuration and control parameters are inserted from the keyboard during the
adjustment and testing operations performed in the factory, but they may be changed later. As the set
cannot be used during the parameter inserting operations, it is necessary to close the stop valve on
the delivery manifold, or all the utilities.
Switch on the electric panel; by default, the system is set in automatic mode. It is possible to pass
from AUTOMATIC to MANUAL mode, and vice versa, by pressing the ↑UP button.
In the case of a system with a pressure sensor, this window appears:
##.## is the current pressure value.
In the case of a system with pressure switches, this window appears
Press the ↓DOWN and OK/MENU buttons until this message appears on the display:
Set the password 00066 with the ↑UP and ↓DOWN buttons and confirm with OK/MENU to enter the
parameters menu.
If the password is wrong, the menu is proposed in read-only mode and this window appears:
6.2.1 SYSTEM
Phase Display
0 SYSTEM
1 PUMPS NUMBER Total number of pumps including
2 JOCKEY PUMP
3 CONTROLLED
BY
36
AUTO
AI1 + ###.## bar
AUT: PRESSURE
SW
-----------
PASSWORD
PARAM.
[00066]
WRONG
PASSWORD
READ ONLY
Comment
any jockey pump.
Indicate presence of jockey pump
Type of sensor used:
Pressure sensor
Temperature sensor
Flow sensor
Level sensor
Pressure switches
Field
1
2
3
YES
NO
PRESS. SENSOR
TEMP.SENSOR
FLOW SENSOR
LEVEL SENSOR
PRESS. SWITCHES
Default
3
NO
PRESS.
SENSOR
