Installation instructions, for professionals only
Thermal safety:
● Heater sensor with overheat cut-out. (Shutdown temperature 139 °C)
● Automatic heat duration limit after max. 6 hours (for private systems).
● Two-sensor system with temperature control over the bench.
Setting ranges:
Temperature for sauna mode:
Fan:
Pre-set time:
Max. pre-set time:
Max. adjustable heating duration:
* EN 60335-2-53 specifies a heating time limitation of 6 h for private saunas. For saunas
in hotels, apartment blocks and similar locations, a maximum heating period limit of
12 hours is permissible. Extending the heating period limit to 18 hours or 24 hours is
only permitted in public saunas.
Connected cables:
Power supply cable:
Heater supply cable (temperature-resistant up to 150 °C):
Sensor wires (temperature-resistant up to 150 °C):
Light wire:
Fan lead:
Maximum cable lengths:
Sensor F1 / F2:
Auxiliary power units:
S2-18:
S2-30:
15–110 °C at bench sensor F2
00–100% fan power
in 1 minute increments
23 hours 59 minutes
6 hours*
10 m
Increase of the switched power of 10.5 kW to
18 kW total power;
Increase of the switched power
from 10.5 kW to 30 kW total power.
p. 33/34
min. 5 x 2.5 mm²
min. 2.5 mm²
min 0.5 mm²
min. 1.5 mm²
min. 1.5 mm²
EN
