Instructions for installation and use

3. Product description

3.1. Scope of delivery

● Operating unit
● Power unit
● Heater sensor with integrated overheat cut-out (F1)
● Bench sensor (F2)
● Sensor wires
● Data cable
● Installation material

3.2. Optional accessories

● Power booster (item number: O-S2-18 / O-S2-30)
● Safety shut-off (item number: HT-SWL)

3.3. Product functions

The CV 41 sauna control unit features the following functions:
● Controls sauna heaters with a heating capacity of up to 10.5 kW.
● A power booster allows the maximum switching capacity to be increased from
10.5 kW to 18 kW or 30 kW.
● Intensity regulation of a fan (up to 100 W).
● Pre-set time function (up to 23 hours 59 minutes)
● Automatic heating period limiter
The sauna control unit shuts down automatically after the maximum heating
period for safety reasons. The maximum heating period can be set to 6 h,
12 h, 18 h or 24 h.
● Overheat cut-out
The overheat cut-out is installed in the housing for the heater sensor. If the
sauna heater continues heating after reaching the preferred temperature
due to a defect, the overheat cut-out switches off at a temperature of approx.
139 °C above the sauna heater.
