Instructions for use for the user

9. Troubleshooting

9.1. Interior lighting does not work

● Switch off the operating switch
● Switch off the light switch
● Turn off main fuses of the control unit in the fuse box.
● Replace light bulb.
● Switch on the control unit again.

9.2. Changing the clock battery

1. Remove the housing cover
"4.1. Installing the power supply unit" on page 10 (Fig. 1).
2. Carefully pull operating unit
3. Replace battery (type CR2032)
4. Insert tabs
3
carefully press onto the housing lower part
5. Place the housing cover
and press until it clicks audibly. Check the fit of the control unit.
WARNING!
Electric shock
Before opening the housing cover, disconnect all poles of the sauna
control unit and secure against reconnection.

9.3. Changing fuses

1. Remove housing cover
unit" on page 10 (Fig. 1).
2. Carefully pull operating unit
3. Replace the fuse for interior lighting B (microfuse 5 x 20 T2.0 A/ 250 V) or
fuse for the electronics of the device A (microfuse 5 x20 T630 mA/ 250 V)
A or fuse for fan 8 (sub-miniature fuse TR5 - T1.0A/250V) (Fig. 1).
1
.
2
of the power supply unit according to
6
2
9
of the operating unit
onto the housing lower part, swivel downward
6
according to "4.1. Installing the power supply
6
2
.
from the housing lower part
for clock on upper board (Fig. 1).
into the two lateral holders
2
to the stop position.
7
from the housing lower part
p. 28/34
.
7
and
4
.
7
