Instructions for installation and use

4.4. Installing bench sensor F2 (optional)

Note Fig. 5 (figures chapter)
The bench sensor must be installed on the wall of the sauna room, above the
rear bench seat. A clearance of approx. 15 cm from the roof of the sauna room
must be maintained.
1. Lay the two 2-pin bench sensor wires in the wall of the sauna room, leading
them to the bench sensor installation location and affix the bench sensor
wires using wire clips.
2. Pull the two half-shells of the bench sensor apart.
3. Connect the two connectors for the bench sensor lead to the two middle
terminals on the connection panel.
4. Place the connection panel crossways in the bench sensor half-shells.
5. Place the two half-shells together and screw them together using the two
cross-head screws (9 mm).
6. Check whether the bench sensor has been securely closed.
7. Install the bench sensor on the wall of the sauna room using the two wood
screws enclosed (16 mm). Maintain a clearance of 15 cm from the roof of
the sauna room.
p. 12/34
