Maintenance; Maintenance By Unqualified Personnel - Igloo Variant Bedienungsanleitung

• Do not open the door unnecessarily and do not leave the open for a longer time
• When you have closed the door, do not force it open. The negative pressure inside is equalized within 1-2
minutes, allowing easy opening of the door.
• Keep the condenser and filter clean. Dirt may cause the compressor overheating, leading to equipment
damage which is not covered by warranty.
• Protect the refrigeration circuit against damage! In case of any suspected depressurization of the refrige-
ration circuit and coolant leakage, ventilate the room and call authorized service.

7.MAINTENANCE

Keep the equipment clan and periodically service it.

7.1. Maintenance by unqualified personnel

An interruption of equipment operation is recommended at least once a month in order to clean the inside, naturally
defrost the evaporator, clean the condenser, check the unobstructed flow to sewers, check the door gaskets, etc.
To clean the equipment:
– Put the light switch and the main switch on the control panel to OFF.
– Disconnect the equipment from the mains – pull out the power cable plug from the outlet
– Empty the equipment
– Wait until the temperature inside reaches the ambient level and the ices evaporator is completely defrosted.
– Check water outflows from the equipment and condensate drains from the evaporator. Check for impurities in this
area, and remove if there are any.
– Check the leak-tightness of connections with sewers (inspect the piping for drips of water)
– (PLUG-IN) Pull out the metal sheets covering the condenser lamellas and check if the condenser is clean – clean
if necessary
– Wash inside and outside with a mild detergent, and then dry.
NOTE: In equipment with hinged door check the condition and cleanliness of the magnetic gasket. Clean or replace if necessary.
- Restart the equipment according to the description in Section 5.3.
Rys. 11 Czyszczenie skraplacza
Rys. 12 Drzwi rozwierne
IGLOO.PL
The condenser must be kept clean. Dirt impedes the heat exchange, causing,
among other things, an increased power consumption and a risk of compressor
damage.
Remove the perforated plate to clean the condenser. Clean the condenser lamellas
with a soft brush or a paintbrush. If the condenser if very dirty (clogged lamellas) use
a vacuum cleaner or compressed nitrogen to suck in/ blow out the dirt accumulated
between the lamellas. Clean the filter on both sides, put it back, and install the per-
forated plate again.
NOTE! During the condenser cleaning wear protective glasses and gloves. Watch
for very sharp lamella edges. Risk of cuts!
Clean the hinged door gasket only with water, without any detergents and dry
it very carefully. The gasket must not be in contact with any greasy or oily
substances.
NOTE: Cracked, broken, damaged door gaskets are an excellent place for growth
of mould, fungi or bacteria. Wash the gaskets once a month with a disinfectant to
prevent the growth of bacteria.
During the maintenance, check if the door closes properly.
Próba: umieścić kartkę papieru pomiędzy uszczelką, a obudową i zamknąć drzwi.
Papier powinien stawiać wyczuwalny opór przy próbie wyciągania.
Instruction manual - cooling and freezing devices
en
15
