Humidity Control - Igloo Variant Bedienungsanleitung

• Put the plug of the power supply cable into the outlet (do not connect the equipment using extension cables or
power strips!)
• The control panel (Fig.8) includes, amongst others: thermostat panel (3) and switches (main switch) (1), light switch
(2)). Pres the main switch to activate the thermostat, and then the refrigeration unit.

5.5. HUMIDITY CONTROL

The basic thermostat function is to control the refrigeration unit in order to obtain the set temperature inside the equipment
and keep it within set intervals. All thermostat setting are made by the manufacturer. Before the first start, the User should
check the required temperature on the panel, and possibly set another temperature.
Digital display – shows current temperature inside the equipment
Any tampering with the thermostat factory settings will render the warranty null and void!
5.5.HUMIDITY CONTROL
NOTE: Applies only to selected refrigerating equipment and can be used only with the IGLOO thermostat.
Fig. 9 STEGO Hygrostat
IGLOO.PL
Fig. 7 Wheelset
A – drive position
B – locked position
A
B
STEGO Hygrostat
The hygrostat is used to control the humidity when the temperature inside the refrige-
rating equipment is in the 10ºC-15ºC range. Use the knob to set the required humidity
in the 40% - 90% range. Turn the knob clockwise to increase the humidity, and antic-
lockwise to reduce it.
Fig. 8 Typical control panel
1 – Main switch (refrigeration unit on/off)
2 – Light switch
3 – IGLOO thermostat panel
Instruction manual - cooling and freezing devices
en
13
