4.2.Unloading

Unload the equipment manually or using a suitable hoist or forklift, always in the position of normal operation. The maxi-
mum inclination angle is 15 degrees. Take notice of the equipment weight and choose a forklift with suitable lifting capacity.
Tall equipment shall be additionally protected against tipping and loss of stability.
Equipment transport in a crate
Fig. 1 Equipment transport
Podczas wjazdu widłami wózka pod urządzenie należy uważać na jego elementy wyposażenia, aby ich nie uszkodzić.
Szczególnie trzeba zwrócić uwagę na: nóżki urządzenia, cokoły, boki urządzeń itd.
5.PREPARING THE EQUIPMENT FOT OPERATION

5.1.Requirements for equipment operation place

The equipment may be used only indoors. Outdoor use is prohibited. The floor on which the equipment will be placed
must be levelled and stable.
Install the equipment in a dry, well-ventilated place, not exposed to direct sunlight. Use curtain/ roller blinds in windows
if necessary. Ensure a good air exchange (distance between the wall and the equipment shall be min. 10 cm), install far
from heat sources and equipment forcing the air flow (air conditioners, ceiling or portable fans, fan heaters – they MUST
NOT blow the air into or extract it from refrigeration equipment!). The equipment works properly in an environment in which
the temperature is within the climate class specified on the rating plate. The equipment operation may deteriorate if for a
longer time it is used in the temperature higher or lower than specified.

5.2.CONNECTING THE EQUIPMENT

5.2.1.Connection with external unit

The installation and first start-up of equipment with an external unit (Remote) shall be performed by suitably,
trained, qualified and licenced personnel. After connecting the equipment and before putting it in operation,
check the tightness of connections and correct operation of the system. Report any leakage in the system
immediately to the nearest service outlet, and use the safety valve to cut off the working medium from the
system.
5.2.2.Installation in lines
If equipment purchased by you is to be connected in a line, you will find all necessary fastening parts (bolts, plugs, and
connecting elements) suitably packed in the installation kit attached do the equipment. The equipment shall be installed
by suitably, trained and qualified personnel.
5.2.3.Connecting to sewers (PLUG-IN type)
Refrigeration/ freezing equipment feature drain funnels for the evaporator trough and/or drip tray. The system
for removal of condensate formed during the defrosting is terminated with a drain funnel or air-trap. The de-
frosting water can be discharged directly to the container placed under the equipment body, can be sent to
electric or gas evaporating tank, or discharged directly to the sewer.
