TECHNICAL DOCUMENTATION – ORIGINAL
TYPE: VARIANT
DOCUMENTATION NO: IN0129
CHAPTER NO.: 022
CHAPTER: OPERATION
NIGHT BLIND (not applicable to racks with DU and DP doors):
The night curtain is placed in the upper part of the counter (inner part of the top shelf). The curtain has a handle
(1) with a clip (2) placed on the inside of the curtain.
Fig. 1
Fig. 3 shows a correctly closed curtain. To roll up (pick up) the curtain, grasp the handle (1) and gently pull down
towards the floor to unlock the catch (2) from the lower curtain holder (3), then tilt it slightly in its direction and still
holding the handle (1), let it roll up completely. IT IS FORBIDDEN TO LET GO OF THE CURTAIN FREELY
AFTER RELEASING THE LOCK. WHEN ROLLING IT UP, IT SHOULD BE SLIGHTLY HELD!
NOTE: The device sent to the Customer is equipped with a paper circuit diagram placed in a special
envelope. The envelope is located close to the device control box (the control panel installation) and
is intended solely for authorized service.
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel.: +48 14/662 19 10
No.
A
B
C
Fig. 2
REVISION
DATE No. DATE
D
E
F
Fig. 3
info@igloo.pl / www.igloo.pl
EN
PAGE: 4/4
1st revision
DATE:
01.07.2022
Fig. 4
