Appendix | Dimensional Drawings and Notes on the Accessories
Fig. 13 Deflection pulley TR1-WDS with mounting foot, dimensions in mm (inches)
wireSENSOR, Z60-M / P96-M / P115-M / P200-M
Adjust the distance,
that the wire can't
snap off!
SW3 DIN911
SW3 DIN911
2xM4 DIN84/912
12
6
(0.47)
(0.24)
40
(1.57)
8.3
(.33)
