Wds-P200-M - MICRO-EPSILON wireSENSOR Z60-M Betriebsanleitung

Functional Principle, Technical Data
7.5.1

WDS-P200-M

Model
Measuring range
Output type
Resolution
Linearity ≤ ±0.01 % FSO
Mean distance per rotation
Suitable encoder
Adapter flange for
encoder Ø 58 mm
Clamping flange
Wire extension force (max.)
Wire retraction force (min.)
Wire acceleration (max.)
Material
Wire mounting
Mounting
Temperature range
Vibration (DIN EN 60068-2-6)
Protection class (DIN EN 60529)
Weight
FSO = Full Scale Output
wireSENSOR, Z60-M / P96-M / P115-M / P200-M
WDS-30000-P200-M
30000 mm
≤ ±3 mm
Flange type Ø 58 mm: synchro flange Ø 6 mm shaft, clamping flange Ø 10 mm shaft
Synchro flange
Housing
Measuring wire
Storage
Operation
WDS-40000-P200-M
depending on the encoder
depending on the encoder
Included in delivery
WDS-EAC 96/200
22 N
12 N
polyamide-coated stainless steel (Ø 0.8 mm)
Eyelet (ø 30 mm)
-40 ... +80 °C (-40 ... +176 °F)
-20 ... +80 °C (-4 ... +176 °F)
20 g / 20 Hz ... 2 kHz in 3 axes and 10 cycles each
depending on the encoder
9.5 kg
WDS-50000-P200-M
40000 mm
≤ ±4 mm
500 mm
22 N
11 N
2 g
Aluminum
Slot nuts
10 kg
50000 mm
≤ ±5 mm
24 N
11 N
11 kg
