Functional Principle, Technical Data
2.3

Technical Data

2.3.1

WDS-1500-Z60-M

Model
Measuring range
Output type
Resolution
Linearity
Mean distance per rotation
Suitable encoder
Adapter flange for encoder
Ø 58 mm
Wire extension force (max.)
Wire retraction force (min.)
Wire acceleration (max.)
Material
Wire mounting
Mounting
Temperature range
Shock (DIN EN 60068-2-27)
Vibration (DIN EN 60068-2-6)
Protection class (DIN EN 60529)
Weight
FSO = Full Scale Output
wireSENSOR, Z60-M / P96-M / P115-M / P200-M
≤ ±0.02 % FSO
Flange type Ø 58 mm: synchro flange Ø 6 mm shaft, clamping flange Ø 10 mm shaft
Synchro flange
Clamping flange
Housing
Measuring wire
Storage
Operation
WDS-1500-Z60-M
1500 mm
depending on the encoder
depending on the encoder
≤ ±0.3 mm
150 mm
WDS-EAS 1
WDS-EAC 1
5.5 N
3.5 N
10 g
Aluminum
polyamide-coated stainless steel (Ø 0.45 mm)
Wire clip
Mounting holes
-40 ... +80 °C (-40 ... +176 °F)
-20 ... +80 °C (-4 ... +176 °F)
50 g / 10 ms in 3 axes, 2 directions and 1000 shocks each
20 g / 20 Hz ... 2 kHz in 3 axes and 10 cycles each
depending on the encoder
0.3 kg
