Functional Principle, Technical Data
2.3.3

WDS-P115-M

Model
Measuring range
Output type
Resolution
Linearity ≤ ±0.01 % FSO
≤ ±0.02 % FSO
Mean distance per rotation
Suitable encoder
Adapter flange for Synchro flange
encoder Ø 58 mm Clamping flange
Wire extension force (max.)
Wire retraction force (min.)
Wire acceleration (max.)
Material
Measuring wire
Wire mounting
Mounting
Temperature range
Shock (DIN EN 60068-2-27)
Vibration (DIN EN 60068-2-6)
Protection class (DIN EN 60529)
Weight
FSO = Full Scale Output
wireSENSOR, Z60-M / P96-M / P115-M / P200-M
WDS-5000-P115-M WDS-7500-P115-M WDS-10000-P115-M WDS-15000-P115-M
5000 mm
-
≤ ±1 mm
Flange type Ø 58 mm: synchro flange Ø 6 mm shaft, clamping flange Ø 10 mm shaft
16 N
4 N
5 g
Housing
Storage
Operation
50 g / 10 ms in 3 axes, 2 directions and 1000 shocks each
1.4 kg
7500 mm
depending on the encoder
depending on the encoder
-
≤ ±1.5 mm
315.07 mm
Included in delivery
WDS-EAC 96/200
24 N
8 N
6 g
Aluminum
polyamide-coated stainless steel (Ø 1.0 mm)
Eyelet (ø 30 mm)
Slot nuts
-40 ... +80 °C (-40 ... +176 °F)
-20 ... +80 °C (-4 ... +176 °F)
20 g / 20 Hz ... 2 kHz in 3 axes and 10 cycles each
depending on the encoder
1.9 kg
10000 mm 15000 mm
≤ ±1 mm ≤ ±1.5 mm
-
21 N 25 N
8 N 8 N
3 g 3 g
2.8 kg 3.2 kg
-
Page 37
