6. Technical data

Electro motor
Power
Revolutions
Saw band length
Saw band width
Saw band width max.
Saw band speed I
Saw band speed II
Cutting height
Opening width
Table size
Slewing range of the table
size of workpiece max.
Weight
The work piece must have a minimum height of 3 mm
and a minimum width of 10 mm.
* Duty type S2 – Short-time duty.
Operation at constant load for 20 minutes or less, fol-
lowed by a time de-energized and at rest of sufficient
duration to re-establish machine temperatures within 2
K of the ambient temperature.
The total noise values determined in accordance with
EN 61029.
Sound pressure level L
pA
Uncertainty K
pA
Sound power level L
WA
Uncertainty K
WA
Wear hearing protection.
The effects of noise can cause a loss of hearing. Total
vibration values (vector sum - three directions) deter-
mined in accordance with EN 61029.
220 - 240 V ~, 50 Hz
550 W (S2 20 min)
1400 min
-1
1790 mm
6 mm
13 mm
660 m/min
960 m/min
0 - 120 mm
245 mm
300 x 300 mm
0° - 45°
580 x 400 x 120 mm
24 kg
77,4 dB(A)
3 dB
90,4 dB(A)
3 dB
www.scheppach.com
7.

Remaining hazards

The machine has been built using modern technology
in accordance with recognized safety rules. Some re-
maining hazards, however, may still exist.
• Risk of injury for fingers and hands by the rotat-
ing saw band due to improper handling of the work
piece.
• Risk of injury through the hurling work piece due
to improper handling, such as working without the
push stick.
• Risk of damaging your health due to wood dust and
wood chips. Wear personal protective cloth such as
goggles. Use a fitting dust extractor.
• Risk of injury due to defective saw band. Regularly
check saw band for such defects.
• Risk of injury for fingers and hands while changing
saw band. Wear proper gloves.
• Risk of injury due to starting saw band while switch-
ing on the machine.
• The use of incorrect or damaged mains cables can
lead to injuries caused by electricity.
• Wear only close fitting clothes. Remove rings,
bracelets and other jewellery.
• For the safety of long hair, wear a cap or hair net.
Even when all safety measures are taken, some
remaining hazards which are not yet evident may
still be present.
• Remaining hazards can be minimized by follow-
ing the instructions in „General safety instructions"
„Proper Use" and in the entire operating manual.

8. Attachment and operation

Before starting the equipment
Make sure the machine stands securely, i.e. bolt it to a
workbench or solid base. There are two holes for this
purpose in the machine foot.
• The saw table must be mounted correctly.
• All covers and safety devices have to be properly
fitted before the machine is switched on.
• It must be possible for the blade to run freely.
• When working with wood that has been processed
before, watch out for foreign bodies such as nails
or screws etc.
• Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
machine's moving parts run smoothly.
• Before you connect the machine to the power sup-
ply, make sure the data on the rating plate is the
same as that for your mains.
