Name
(hex)
424
Lock/Kill Selector
(0x1A8)
1 (0x01) Command
2 (0x02) User memory
3 (0x03) EPC
4 (0x04) TID
5 (0x05) Tag access pass- word
6 (0x06) Tag kill password
1)
ro = read only, wo = write only, rw = read/write
8.3.2.10
Data standards
Index dec
Name
(hex)
430
Decode tag data
(0x1AE)
8026853/1HLX/2022-09-30 | SICK
Irrtümer und Änderungen vorbehalten
Format
Length
Access
(Offset)
1)
Record
6 Byte
rw
Bit (40)
8 Bit
rw
Bit (32)
8 Bit
rw
Bit (24)
8 Bit
rw
Bit (16)
8 Bit
rw
Bit (8)
8 Bit
rw
Bit (0)
8 Bit
rw
Format
Length
Access
(Offset)
1)
UInt
8 Bit
rw
Default
Value / Range
Value
-
-
0
0 = Lock
1 = Kill
0
0 = Preserve
1 = Unlock
2 = Lock
3 = Unlock per‐
manently
4 = Lock perma‐
nently
0
0 = Preserve
1 = Unlock
2 = Lock
3 = Unlock per‐
manently
4 = Lock per‐
man- ently
0
0 = Preserve
1 = Unlock
2 = Lock
3 = Unlock per‐
manently
4 = Lock perma‐
nently
0
0 = Preserve
1 = Unlock
2 = Lock
3 = Unlock per‐
manently
4 = Lock perma‐
nently
0
0 = Preserve
1 = Unlock
2 = Lock
3 = Unlock per-
manently
4 = Lock perma‐
nently
Default
Value / Range
Value
0
0 = No decoding
is used
1 = VDA coding
scheme is used
2 = IATA coding
scheme is used
B E T R I E B S A N L E I T U N G | RFU61x IO-Link
8
BEDIENUNG
Remark [Unit]
-
Defines the command Lock
or Kill
Bank UserMemory
Bank EPC
Bank TID
Bank reserved (area tag)
Bank reserved (area kill)
Remark [Unit]
Specifies current coding
scheme of tag data to be
used for decoding
55
