1.4
1.4.1 CAN ID
EN
Book_81307110_CA44x.indb 6 Book_81307110_CA44x.indb 6
CAN
A CAN network is of multi drop type which means that all units are connected in parallel on the
same cable. In a CAN network every unit must have a unique address or ID-number.
On the CA 44x series one part of the address is set default depending on type of device, the other
part of the address is set by a hexadecimal switch, marked "ID". Choose address by pump number
as in table below. If the device has a unique address and contact with the network master, the CAN
LED is still fixed green. For error codes of the CAN LED see PC 441 User guide.
Use the following addresses to achieve correct functions.
Table 1. CA 441 Leakage monitor
CAN SUB ID Monitoring function
0 Not used with PC 441
1 Pump 1 or pumps 1-4
2 Pump 2
3 Pump 3
4 Pump 4
5 - > F Not used with PC 441
Table 2. CA 442 Temperature monitor
CAN SUB ID Monitoring function
0 Not used with PC 441
1 Pump 1 or pumps 1-4
2 Pump 2
3 Pump 3
4 Pump 4
5 Pump 1 & Pump 2
6 Pump 3 & Pump 4
7 - > F Not used with PC 441
Table 3. CA 443 Power monitor
CAN SUB ID Monitoring function
0 Main power monitor
1 Pump 1
2 Pump 2
3 Pump 3
4 Pump 4
5 - > F Not used with PC 441
6
