Technical data

HardBoot plus
AC input
AC output
Switching current
(max.)
Fuse
Power supply
HardBoot controller
Network
Network connection
Protocols
Expandable with
slave devices
Connection for
slave devices
serial access
Operating temperature 0 - 50 °C
Humidity
Casing (W x H x D)
Weight
HardBoot CCX
AC input
AC output
Switching current
(max.)
Fuse
RS485 interface
Operating temperature 0 - 50 °C
Humidity
Casing (W x H x D)
Weight
200 - 250V
2 x IEC plugs (IEC 60320 C14)
2 x 4 sockets (IEC 60320 C13)
10 A per device for the two separate circuits
10 A permanent current, 120 A peak current per user
2 x 10 A delay
redundant, via one or both of the connected power supplies,
switches automatically
IEE 802.3 - 10BaseT
1 x RJ45 socket
TCP/IP
expansion with a max. of 4 HardBoot CCX possible
1 x RJ45 socket
D-Sub 9
10 - 80%, non-condensing
485 x 45x 150 mm
19" x 1 U x 150 mm
2,4 kg
200 - 250V
2 x IEC plugs (IEC 60320 C14)
2 x 4 IEC sockets (IEC 60320 C13)
10 A per device for the two separate circuits
10 A permanent current, 120 A peak current per user
2 x 10 A delay
2 x RJ12 socket (x link)
10 - 80%, non-condensing
485 x 45x 150 mm
19" x 1 U x 150 mm
2,4 kg
Technical data
