Extended functions

Changing the configuration of the HardBoot system

If you change the IP address of the HardBoot plus, the new address has to be entered
in the software. That way, a connection to the HardBoot system can be established.
You also have the possibility to change the system name the software displays or to
file slave devices.
How to change the configuration of the HardBoot system in the software:
1. Click on the entry HardBoot configuration (HardBoot-Konfiguration) in the Settings
(Einstellungen) menu.
2. Enter the administrator password and confirm your entry by clicking the OK button.
The administrator password only needs to be entered if no administrating func-
tion has been called up in the current session.
3. Select that HardBoot system from the overview whose settings you want to
change.
4. Click the Change (Ändern) button. Now, the following dialogue window appears:
Figure 15: Dialogue window "Settings HardBoot" ("Einstellungen HardBoot")
5. Check and, if necessary, change the following data in the field General (Allgemein)
of the dialogue window:
a. Name: Enter the desired name of the HardBoot system. This name is displayed
in the graphical interface of the software.
b. IP-Adresse (IP address): Enter the IP address of the HardBoot system. If a perma-
nent IP address has been assigned to the HardBoot plus, you can read it out in
the configuration menu (see "Network configuration" on page 8 ff).
c. Username: Enter the username of the administrator's account of the HardBoot
system (default setting: admin).
d. Password (Passwort): Enter the password of the administrator's account of the
HardBoot system (default setting: admin).
Operating with HardBoot view
G&D HardBoot plus · 22
