Operating with HardBoot view
8. The dialogue Configuration power outlet groups (Konfiguration Steckdosengruppen)
shows you the entry of the new groups. The dialogue column Info displays the
allocated power outlets:
Figure 19: Display of the new group in the configuration dialogue
9. Click the OK button to end the configuration of the power outlet groups.
Switching the power supply of a power outlet group corresponds to the instruc-
tions in the chapter "Switching the power supply" on page 19.
How to change the allocation of single power outlets to a power outlet group:
1. Click on Group allocation (Gruppenzuordnung) in the Settings (Einstellungen) menu.
2. Enter the administrator password and confirm the entry by pressing the OK button.
The administrator password only needs to be entered if no administrating func-
tion has been called up in the current session.
3. An overview of the already configurated power outlet groups appears.
4. Right-click with the mouse on the power outlet group you want to change and
click on the command Edit (Bearbeiten) in the context menu:
Figure 20: Edit (Bearbeiten) entry in the context menu
5. Check and, if necessary, change the desired name of the power outlet group in
the field Name.
6. The area Allocated power outlets (Zugeordnete Steckdosen) provides three drop-down
lists to select one power outlet each. Click on the arrow on the right sight of the
drop-down list to see a list of all power outlets of the HardBoot system that have
not been grouped yet.
7. Check and, if necessary, change the allocated power outlets of the group.
8. Click the OK button to return to the overview dialogue of the power outlet
groups.
