Operating with HardBoot view

Switching the power supply

It is possible to both turn on or turn off the power supply of single power outlets or
of a power outlet group at all times. Directly after the switching through the soft-
ware HardBoot view, the power supply of the power outlet/group is established or
disconnected by the HardBoot system.
How to turn on/off the power supply of a power outlet/group:
1. Within the overview of power outlets, double click on the power outlet/group
that you want to turn on/off.
As an alternative to the double click, the following actions are also possible:
Right-click with the mouse on the power outlet/group and select in the con-
text menu the menu point Turn on/off device (Gerät ein-/ausschalten) .
Select the power outlet/group and click on the entry Turn on/off (Ein-/Aus-
schalten) in the Edit (Bearbeiten) menu.
2. The dialogue Turn on/off device (Gerät ein-/ausschalten) displays the status of the
selected power outlet or power outlet group:
Figure 13: Dialogue turn on/turn off the device
3. Click the Turn on (Einschalten) or Turn off (Ausschalten) button. If you do not want
to switch the power outlet, skip this point.
4. Click the Close (Schließen) button to close the dialogue.
