Gemü 567 servoDrive Betriebsanleitung Seite 28

7 Abmessungen
7.2.14 Clamp mit Bypass Code 88
AG DN
Sitz-
größe
(Code)
2 15 A
B
C
D
20 A
B
C
D
E
G
Maße in mm
1) Anschlussart
Code 88: Clamp ASME BPE
GEMÜ 567 servoDrive
L
LE H1
d1
d3
L
□E
53,0 75,0
53,0 75,0
53,0 75,0
53,0 75,0
53,0 75,0
53,0 75,0
53,0 75,0
53,0 75,0
53,0 75,0 10,0
53,0 75,0 15,0
Anschlussart Code 88
Werkstoff Code 41, 43
Øz LE1 LE2
2,0 67,8 74,20
4,0 67,8 73,20
6,0 67,8 72,20
8,0 67,8 71,20
2,0 64,6 77,38
4,0 64,6 76,38
6,0 64,6 75,38
8,0 64,6 74,38
64,6 73,38
64,6 70,88
28 / 47
1)
H1 H2 cz
18,2 41,20 3,70
18,2 40,20 2,70
18,2 39,20 1,70
18,2 38,20 0,70
21,4 44,38 6,88
21,4 43,38 5,88
21,4 42,38 4,88
21,4 41,38 3,88
21,4 40,38 2,88
21,4 37,88 0,38
www.gemu-group.com
Ød1 Ød3
9,40 25,0
9,40 25,0
9,40 25,0
9,40 25,0
15,75 25,0
15,75 25,0
15,75 25,0
15,75 25,0
15,75 25,0
15,75 25,0
