7.2 Körpermaße
7.2.1 Stutzen ohne Bypass Code 0
c
AG DN
Sitz-
größe
(Code)
2 15 A
B
C
D
E
G
3 20 H
25 H
J
Maße in mm
1) Anschlussart
Code 0: Stutzen DIN
www.gemu-group.com
L
s
LE
H1
d
L
□E
45,0 75,0 20,0
45,0 75,0 20,0
45,0 75,0 20,0
45,0 75,0 20,0
45,0 75,0 20,0
45,0 75,0 20,0
55,0 95,0 25,0
55,0 95,0 25,0
55,0 95,0 25,0
Anschlussart Code 0
Werkstoff Code 41, 43
c Øz LE
2,0 44,0
4,0 44,0
6,0 44,0
8,0 44,0
10,0 44,0
15,0 44,0
20,0 54,0
20,0 54,0
25,0 54,0
15 / 47
1)
H1 H2 cz
21,0 40,5 6,5
21,0 39,5 5,5
21,0 38,5 4,5
21,0 41,0 3,5
21,0 40,0 2,5
21,0 37,5 0,0
26,0 50,0 0,0
26,0 50,0 2,5
26,0 47,5 0,0
GEMÜ 567 servoDrive
7 Abmessungen
Ød s
18,0 1,5
18,0 1,5
18,0 1,5
18,0 1,5
18,0 1,5
18,0 1,5
22,0 1,5
28,0 1,5
28,0 1,5
