Gemü 567 servoDrive Betriebsanleitung Seite 16

7 Abmessungen
7.2.2 Stutzen ohne Bypass Code 17
c
DN
Sitz- L
größe
(Code)
8 A 45,0
B 45,0
C 45,0
10 A 45,0
B 45,0
C 45,0
D 45,0
15 A 45,0
B 45,0
C 45,0
D 45,0
E 45,0
G 45,0
Maße in mm
1) Anschlussart
Code 17: Stutzen EN 10357 Serie A (ehemals DIN 11850 Reihe 2) / DIN 11866 Reihe A
2) Werkstoff Ventilkörper
Code 41: 1.4435 (316L), Vollmaterial
GEMÜ 567 servoDrive
L
s
LE
H1
d
c
□E
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
Anschlussart Code 17 1)
Werkstoff Code 41 2)
Øz LE H1
2,0 47,5 17,5
4,0 47,5 17,5
6,0 47,5 17,5
2,0 46,5 18,5
4,0 46,5 18,5
6,0 46,5 18,5
8,0 46,5 18,5
2,0 43,5 21,5
4,0 43,5 21,5
6,0 43,5 21,5
8,0 43,5 21,5
10,0 43,5 21,5
15,0 43,5 21,5
16 / 47
H2 cz Ød
40,5 3,0 10,0
39,5 2,0 10,0
38,5 1,0 10,0
41,5 4,0 13,0
40,5 3,0 13,0
39,5 2,0 13,0
38,5 1,0 13,0
44,5 7,0 19,0
43,5 6,0 19,0
42,5 5,0 19,0
41,5 4,0 19,0
40,5 3,0 19,0
38,0 0,5 19,0
www.gemu-group.com
s
1,0
1,0
1,0
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
