Gemü 567 servoDrive Betriebsanleitung Seite 25

7.2.11 Clamp ohne Bypass Code 88
LE1
AG DN
Sitz-
größe
(Code)
2 15 A
B
C
D
20 A
B
C
D
E
G
3 25 H
Maße in mm
1) Anschlussart
Code 88: Clamp ASME BPE
www.gemu-group.com
L
H1
d1
d3
L Øz
□E
45,0 75,0 2,0
45,0 75,0 4,0
45,0 75,0 6,0
45,0 75,0 8,0
45,0 75,0 2,0
45,0 75,0 4,0
45,0 75,0 6,0
45,0 75,0 8,0
45,0 75,0 10,0
45,0 75,0 15,0
55,0 95,0 20,0
Anschlussart Code 88 1)
Werkstoff Code 41, 43
LE1 LE2 H1
59,8 74,20 18,2
59,8 73,20 18,2
59,8 72,20 18,2
59,8 71,20 18,2
56,5 77,38 21,4
56,5 76,38 21,4
56,5 75,38 21,4
56,5 74,38 21,4
56,5 73,38 21,4
56,5 70,88 21,4
66,8 87,60 26,3
25 / 47
7 Abmessungen
H2 cz Ød1
41,20 3,70 9,40
40,20 2,70 9,40
39,20 1,70 9,40
38,20 0,70 9,40
44,38 6,88 15,75
43,38 5,88 15,75
42,38 4,88 15,75
41,38 3,88 15,75
40,38 2,88 15,75
37,88 0,38 15,75
48,60 1,10 22,10
GEMÜ 567 servoDrive
Ød3
25,0
25,0
25,0
25,0
25,0
25,0
25,0
25,0
25,0
25,0
50,5
