5.2 Körpermaße
5.2.1 Stutzen ohne Bypass Code 0
c
DN
Sitz- L
größe
(Code)
15 A 45,0
B 45,0
C 45,0
D 45,0
E 45,0
G 45,0
20 A 45,0
B 45,0
C 45,0
D 45,0
E 45,0
G 45,0
H 55,0
25 H 55,0
J 55,0
Maße in mm
1) Anschlussart
Code 0: Stutzen DIN
2) Werkstoff Ventilkörper
Code 41: 1.4435 (316L), Vollmaterial
Code 43: 1.4435 (BN2), Vollmaterial, Δ Fe < 0,5 %
www.gemu-group.com
L
s
LE
H1
d
□ E c
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
95,0 25,0
95,0 25,0
95,0 25,0
Anschlussarten Code 0 1)
Werkstoffe Code 41, 43 2)
Ø z LE H1
2,0 44,0 21,0
4,0 44,0 21,0
6,0 44,0 21,0
8,0 44,0 21,0
10,0 44,0 21,0
15,0 44,0 21,0
2,0 42,0 23,0
4,0 42,0 23,0
6,0 42,0 23,0
8,0 42,0 23,0
10,0 42,0 23,0
15,0 42,0 23,0
20,0 - -
20,0 52,5 27,6
25,0 52,5 27,6
15 / 45
H2 cz Ø d
40,5 6,5 18,0
39,5 5,5 18,0
38,5 4,5 18,0
41,0 3,5 18,0
40,0 2,5 18,0
37,5 - 18,0
46,0 8,5 22,0
45,0 7,5 22,0
44,0 6,5 22,0
43,0 5,5 22,0
42,0 4,5 22,0
39,5 2,0 22,0
- - -
50,0 2,5 28,0
47,5 0,0 28,0
GEMÜ 567 BioStar control
5 Abmessungen
s
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
-
1,5
1,5
