English
– Weight without battery: 3.7 kg
– Degree of electrical protection: IPX4 (protec‐
tion against splash water from any direction)
The running time is shown at www.stihl.com/
battery-life.
19.2 Cutting blades
– Tooth spacing: 34 mm
– Cutting length: 600 mm
– Sharpening angle: 45°
19.3 STIHL AP battery
– Battery technology: lithium-ion
– Voltage: 36 V
– Capacity in Ah: see rating label
– Energy content in Wh: see rating label
– Weight in kg: see rating label
– Permissible temperature range for operation
and storage: + 10 °C to + 50 °C
®
– Bluetooth radio interface (only for batteries
with ):
– Data connection: Bluetooth
mobile appliance must be compatible with
®
Bluetooth Low Energy 5.0 and support
Generic Access Profile (GAP).
– Frequency band: ISM band 2.4 GHz
– Maximum RF power transmitted: 1 mW
– Signal range: approx. 10 m. The signal
strength depends on the ambient conditions
and the mobile terminal. Signal range can
vary greatly depending on local conditions,
including the receiver. The range may be
perceptibly reduced inside enclosed rooms
and through metal barriers (such as walls,
shelves or cases).
– Mobile appliance operating system require‐
ments: Android or iOS (current version or
higher)
19.4 Sound Values and Vibration
Values
The K-value for the sound pressure level is
2 dB(A). The K-value for the sound power level is
2 dB(A). K-value for vibration level is 2 m/s².
STIHL recommends wearing ear defenders.
– Sound pressure level L
to EN 62841-4-2: 76 dB(A).
– Sound power level L
EN 62841-4-2: 84 dB(A).
– Vibration value a
hv
EN 62841-4-2:
– Control handle: 0.8 m/s².
– Loop handle: 1.0 m/s².
34
®
5.1. The
measured according
p
measured according to
wA
measured as per

20 Spare Parts and Accessories

The vibration levels indicated were measured
according to a standardized test method and can
be used as a basis for comparing electric power
tools. The vibration levels actually occurring may
vary from the values indicated, depending on the
type of application. The vibration levels indicated
can be used for an initial estimate of the vibration
stress. The actual vibration stress has to be esti‐
mated. The times can be taken into account in
the estimate when the electric power tool is
switched off and also when it is switched on but
running without any load.
For information on compliance with Employers'
Vibration Directive 2002/44/EC see
www.stihl.com/vib.
19.5 REACH
REACH is an EC regulation and stands for the
Registration, Evaluation, Authorisation and
Restriction of Chemical substances.
For information on compliance with the REACH
regulation see www.stihl.com/reach.
20 Spare Parts and Accesso‐
ries
20.1 Spare parts and accessories
These symbols indicate original STIHL
spare parts and original STIHL acces‐
sories.
STIHL recommends the use of original STIHL
spare parts and accessories.
Despite ongoing market observation, STIHL is
unable to judge the reliability, safety and suitabil‐
ity of other manufacturers' spare parts and
accessories; accordingly, STIHL cannot warrant
for the use of those parts.
Original STIHL spare parts and original STIHL
accessories are available from STIHL dealers.

21 Disposal

21.1 Disposing of Hedge Trimmer
and Battery
Contact the local authorities or your STIHL
dealer for information on disposal.
Improper disposal can be harmful to health and
pollute the environment.
► Take STIHL products including packaging to a
suitable collection point for recycling in accord‐
ance with local regulations.
► Do not dispose with domestic waste.
