Krick Modelltechnik Karl und Marie Bauanleitung Seite 32

Part-No. Description
43 Jib
44 Guide eye
45 Retaining eye
46 Cleat
47 Pin rail
48 Pin rail
49 Pin rail
50-63 Cleats
64-77 Eye-bolt on deck
78-109 Belaying pins
110 Channel fitting
111 Channel irons
112 Channel deadeye
113 Backstay iron
114 Foot grate
115 Steering wheel
116 Trestle
117 Trestle
118 Drum
119 Axle
120 Water barrels
121 Bearing, top
122 Bearing, bottom
123 Tension rods
124 Deckhouse, side
125 Deckhouse, side
126 Deckhouse, front
127 Deckhouse, back
128 Corner strips
129 Roof
130 Planking strips for walls
131 Door
132 Planking strips for roof
133 Bull's eyes
134 Cleat
135 Cleat
136 Main boom sheet lead boom
137 Retaining blocks
138 Side coaming
139 End coaming
140 Hatch
141 Planking strips for coaming
142 Planking for hatch
143 Eye-bolt
Quantity Material
2 Beech wood, 5 x 5 x 28
2 Eye-bolt, finished part
2 Eye-bolt, finished part
2 Brass wire, 0,5 x 20
1 Plywood, 1,5 mm, laser sheet 5
2 Plywood, 1,5 mm, laser sheet 5
4 Plywood, 1,5 mm, laser sheet 5
14 Finished part
14 Finished part
32 Finished part
12 Finished part
12 Finished part
12 Finished part
2 Finished part
14 Walnut, 0,5 x 2 x 20
1 Finished part
1 Plywood, 3 mm, laser sheet 7
1 Plywood, 3 mm, laser sheet 7
1 Ramin, 5 x 12
2 Brass wire, 1,5 x 10
3 Finished part
2 Beech wood, 3 x 5 x 55
2 Beech wood, 3 x 3 x 55
8 Brass wire, 1,5 x 22
1 Plywood, 1,5 mm, laser sheet 5
1 Plywood, 1,5 mm, laser sheet 5
1 Plywood, 1,5 mm, laser sheet 5
1 Plywood, 1,5 mm, laser sheet 5
4 Pine, 3 x 3 x 45
1 Plywood, 1,5 mm, laser sheet 5
1 Walnut, 0,5 x 5 x 2600 overall
1 Walnut, 0,5 x 3 x 300 overall
1 Tanganjica, 0,5 x 5 x 850 overall
3 Finished part
1 Off-cut wood
1 Off-cut wood
1 Ramin, 4 x 65
2 Beech wood, 6 x 6 x 12
2 Plywood, 1,5 mm, laser sheet 5
2 Plywood, 1,5 mm, laser sheet 5
1 Plywood, 1,5 mm, laser sheet 5
1 Walnut, 0,5 x 5 x 420 overall
1 Tanganjica, 0,5 x 5 x 660
16 Finished part
