MICRO-EPSILON optoCONTROL 1200 Betriebsanleitung Seite 50

Functional Principle, Technical Data
Model
Shock (DIN-EN 60068-2-27)
Vibration (DIN-EN 60068-2-6)
Protection class
(DIN-EN 60529)
Material
Weight
Light source
Measuring programs
Control and indicator elements
Special features
FSO = Full Scale Output
The quoted data apply for a constant room temperature of 20 °C after a warm-up period of 180 min, in the range 10 ... 90 % of the ana-
log output at a distance of 150 mm between light source and receiver without ambient light effect.
Analog offset if laser beam is covered without ambient light < 0.05 V
1) Linearity and resolution decrease with larger distances.
2) Applies in the mid of the measuring range for distance: target - receiver 20 mm; distance: light source - receiver 150 mm
3) For gap measurement 50 ... 400 µm, an option is available with a regulated controller for transmitted light operation and measure-
ment distance up to 700 mm.
4) The specified values apply at ±2 sigma
5) Measured in the mid of the measuring range with static noise over 3 min.
6) With direct or indirect irradiation, daylight shading increases the stability of the measurement
7) Connection via interface module (see
optoCONTROL 1200/1201
ODC 1200 (axial model)
Receiver /
light source
Receiver /
light source
Receiver approx. 150 g
approx. 120 g
Receiver (LED) indication: switching state indicator and dirt with free beam path
Measurements server for transmission of several measurements to the PC;
accessories, see A
ODC 1200/90 (90 ° model)
15 g / 6 ms
15 g / 0.01 ... 1 kHz
IP67
Aluminum housing
Edge
(outer-) diameter / width
gap
Light source (LED) indication: power ON/OFF
(optional IF1032/ETH)
1)
approx. 170 g
approx. 160 g
ODC 1201
approx. 260 g
approx. 220 g
