Refill and replace filter material

1. Detach hoses from control valve
2. Detach control valve from pressure tank
3. Fill in Filtermaterial
Multi 7000 only:
1. Detach control valve from pressure tank
2. Unscrew Adapter (Z)
3. Cover central tube's upper end
NOTE: No Filtermaterial must fall into the central tube!
4. Fill in Filtermaterial
Multi C 1000
Multi C 2000
Multi C 3000
Multi C 7000
X
Use the enclosed o-ring lubricant.
When filling ist done:
1. Attach control valve to pressure tank
2. Attach water suply hoses IN (7) and OUT (6) on control valve
3. Carry out backwashing (see initial start-up).
Multi 7000 only:
1. Remove cover from central tube
2. Screw in adapter (Z)
3. Attach control valve.
4. Attach water suply hoses IN (7) and OUT (6) on control valve
5. Carry out backwashing (see initial start-up).
The filter is ready for use again.
Clearance X
140 mm
235 mm
300 mm
300 mm
(Z) Adapter Multi 7000 C
