6.1

Checklist

You can use this list to check your work again after you have installed
and started the unit.
Is there a protective filter upstream from the unit in the im-
mediate vicinity?
Is the water and power supply to the unit continuous (network
pressure of at least 2 bar)?
Is the Multiblock opened to the limit stop?
Have the connection hoses been properly connected? (Obser-
ve flow direction arrows, drinking water inlet at the non-return
valve of the unit)
Has the flushing water hose been routed separately to the
sewage system and connected in compliance with local
standards? (See Installation)
7

Start-up

7.1

Operating the controller

Keypad
Function of keys
Confirms entries
Moves the cursor, modifies input values
Moves the cursor
The Turn page button toggles between the
Operating and Selection displays
Operating display
Display alternates between showing the day of
the week and the time of day and the remaining
2 14 : 49
capacity in litres.
In Programming mode, the following items flash:
1 = Monday
4448 L
2 = Tuesday
3 = Wednesday
...
7.2

Factory settings

Operating range
Automatic backwash after 96 hours if remaining capacity is not 0
Multi C 1000
Multi C 2000
Multi C 3000
Multi C 7000
tP1 = 1-2 residential units
900 Litre
1800 Litre
2400 Litre
6000 Litre
