Operating and installation instructions
EN
25/06/2021 10:14
Water valve On
Water valve Off
Drain pump On
Drain pump Off
UVC tube On
UVC tube Off
Rotor rotating
Heating On

9.3. Main menu

By pressing the
individual submenu items.
button leads back to the main overview.
KWL Hygrobox KWL HBX EH/WW
®
button in the main overview, you reach the main menu of the control unit. From there, you can navigate to the
The blue arrow indicates an airflow through the KWL HBX.
Indication of the currently measured relative humidity and air temperature
at the outlet of the KWL HBX.
Date / time: Can be changed directly by touching the display.
Activation / deactivation of the summertime can be carried out.
When the power supply is interrupted for a longer period of time, the
settings must be checked and updated, if necessary.
Indicates the current status of the water valve. In the humidification mode,
the humidifier tank is continually filled with fresh drinking water.
Indicates the current status of the drain pump. It is active in each starting
sequence, switch-off sequence, change to the standby mode as well as
humidification mode, if the water level in the humidifier tank is too high.
Indicates the current status of the UVC tube. It is always switched on with
active air humidification and during the switch-off sequence.
Indicates the current operating status of the rotor. It rotates in the humidifi-
cation mode and during the switch-off sequence.
Indicates the current operating status of the heater battery. It is only active
during active humidification.
16
Operating values and
unit information
Messages
Settings
Service / maintenance
