EN
Filling the tank with water
Remove the tank D from the coffee machine, open the lid D1 and fill it with water preferably
at room temperature (the water level must be between the MIN and MAX marks). Then put
the tank back in place.
Filling with coffee beans
Remove the lid F4 and fill the container F3 with coffee beans to the brim and then close the
container F3 with the lid F4.
Removing operational components
Looking at the camera that is used more often with the coffee machine (aluminium lever C,
drip tray E, coffee bean container F3), proceed as shown in Fig. 1. Proceed in reverse order
to put the components back.
Rinsing the coffee maker
At the first start-up or if you have not used the coffee machine for more than 2 days, flush
it using the following procedure:
1. Fill tank D with water up to the MAX mark.
2. Place lever C and the stainless-steel bowl (C1/C2/C3/C4) on the coffee machine as
shown in Figure 2.
3. Connect the machine to the mains. Make sure that the rotary knob A1 is in the „ "
position.
4. The coffee machine must be switched on by pressing B1 button (an acoustic signal
sounds).
5. Wait for the coffee machine to warm up sufficiently (all buttons will be lit continually).
6. Place a suitable vessel of sufficient volume below the coffee outlet or use 2 bigger cups
which will be alternated in the course of rinsing, emptying the water in the cups.
7. Make several cups (without coffee) using buttons B3/B4). We recommend rinsing the
coffee machine 3 to 5 times using this procedure.
When rinsing, the coffee machine produces hot water.
IV. USING THE APPLIANCE
– Light indicator B1 flashes when the coffee machine is heating. After warming up, the
light on all buttons is continually on.
– When water in tank D is off, sound signal will be issued and light indicators of buttons
B1 and B2 will be flashing alternatively and light indicators of buttons B3 and B4 will
be flashing simultaneously.
– The coffee brewing can be stopped at any time by pressing the corresponding B3/B4
button.
– When the coffee brewing is on, the A1 knob must be in the „ ", position, otherwise the
coffee brewing function cannot be switched on.
– If adjusting knob A1 will be turned to „
NOTICE
Remarks
" or „ ", coffee preparation will be stopped.
30 / 71
