10.7. Module Information

The module information feature allows getting data on the Safe I/O Module to monitor its current state.
To perform a module information follows the below procedure:
Note!
The procedure is based on the assumption that the module is in an unknown state but
has a known IP address. If the module IP address is unknown, go to the
section.
1. Launch the SNCT
2. Create a new project and select the module type.
3. Select the network interface.
4. Perform a module discovery and select the module.
5. Go Online to connect the module (Action/Online)
6. At this step, two warnings are displayed depending of the module state:
a. TUNID configured is different from TUNID in the module (providing a TUNID is not mandatory
to retrieve module Information).
b. Parameters in the module are different from parameters in the configuration. This is normal
because you have created a new project.
7. Select Module Information tabs and click on the Refresh Button.
