CHIPCARD option

An option to increase independence and flexibility, using two types of ChipCards to transfer data between
members of the F-SCAN family, was designed into the F-SCAN3 NT.
Program data consisting of frequency values only can be shared between F-SCAN3 NT, F-SCAN4, F-SCAN5,
F-SCAN COMPACT and the MinDevice using the ChipCard.
The use of the ChipCard PLUS allows the transfer of all types of program data sets to and from F-SCAN3 NT,
F-SCAN4, F-SCAN5 and F-SCAN MOBILE.
Insert the ChipCard vertically into the reader on right hand side of the device.
The menu ChipCard opens and offers 4 choices:
- Touch the first line to save all of the 100 program positions, which hold frequencies only, on the ChipCard for
use in an F-SCAN COMPACT.
- Touch the second line to overwrite the 100 program positions of the F-SCAN3 NT with the data from an
F-SCAN COMPACT. DIRP- or EAP-data sets previously stored in program positions in the F-SCAN3 NT will
be lost.
- Touch the third line to store the frequency values of the program position presently open in the F-SCAN3 NT
on the ChipCard for use in a MinDevice.
- Touch the fourth line to erase all data from the ChipCard.
Removal of the ChipCard from the reader resets the F-SCAN3 NT to the menu active when the ChipCard was
inserted.

Use of the ChipCard PLUS

The following menu opens when a ChipCard PLUS is inserted into the reader:
- Touch the first line to store the content of the memory with the 100 program positions on the ChipCard PLUS.
- Touch the second line to overwrite the 100 program positions of the F-SCAN3 NT with the data from the
ChipCard PLUS.
- Touch BACKUP ABC LIST to store the ABC list on the ChipCard PLUS.
-
Touch RESTORE ABC LIST to copy the ABC list from ChipCard into the device. An already installed ABC
list will be overwritten.
