How to prepare for a DIRP and run it
Assumption: perform a DIRP analysis in the frequency range between 80000 Hz and 560000 Hz:
1.
Attach the DIRP sensor following the instructions shipped with it.
2.
Plug the connector of the DIRP-sensor cable into the device's output and connect the red wire to
the cylinder. Hold the cylinder in the left hand.
3.
Touch the button
4.
Wait until the graph line reaches Fmax and completes the procedure or touch the button
end the analysis at any point. During a DIRP procedure, the reaction time of a touch may take up to
1 second.
5.
Touch the button
will overwrite any data previously stored in that position.
START
to start the analysis
SAVE
to store the complete DIRP results in the selected program position. This
- 18 -
STOP
to
