The menu SWEEP
A touch on the icon "SWEEP" opens the screen to start the broad band frequency swing "SWEEP".
SWEEP can be used to swing for a limited time (standard 20 minutes) through a broad band of frequencies
between a lower limit "Fmin" and an upper limit "Fmax". The step size "DELTA F" from value can be entered.
"Fmin", "Fmax" and "DELTA F" can be set by touching the icons Fmin and Fmax and DELTA F..
The signal form is "AUTO", which means "SQUARE DC-OFFSET" through 65000 Hz and "SINE" above that
value.
The amplitude is as selected in menu "123".
Touch the button icon START to start the procedure. The output moves from "Fmin" up to "Fmax", turns
around to move back to "Fmin", and so on, until the time of 20 minutes is up. The activity is simultaneously
displayed on the screen.
A touch on the icon STOP stops the procedure at any point.
