Lower the load by firmly grasping the winch handle and rotating it away from the mast. After lowering to the
desired position, turn the winch handles toward the mast (raise the load) 1/4 turn to set the brakes.
It is best to move the machine on the worksite with no load. Moving a raised load should be restricted to
positioning only.

After each use

To prepare the truss lifter for storage, follow the setup procedure in reverse order.
Select a safe storage location - firm level surface, weather protected, clear of obstruction and traffic.

Transport instructions

The transport vehicle must be parked on a level surface.
The transport vehicle must be secured to prevent rolling while the machine is being loaded.
Be sure the vehicle capacity, loading surfaces and chains or straps are sufficient to withstand the machine
weight.
The machine must be secured to the transport vehicle with chains or straps of ample load capacity.
Loading the machine
Fully lower the carriage.
Lock every section.
Lock every outrigger. Be sure the spring pins are properly inserted.
Place the machine against the vehicle. Use proper lifting techniques to load the machine into the transport
vehicle.
The machine must never be loaded with a crane!

CLEANING AND MAINTENANCE

The operator has to make sure that safety-relating and machine-technical installations are inspected by an
expert after every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are inspected by a
skilled person once a year.
1) The following points have to be considered during the inspection:
2) The standing stability of the stand has to be checked.
3) All carrying parts have to be inspected on damages or material fatigue.
4) All screws used for installing the devices or parts of the device have to be tightly connected and must not
be corroded.
5) There must not be any deformations on housings, fixations and installation spots (ceiling, suspension,
trussing).
6) Mechanically moved parts like axles, eyes and others must not show any traces of wearing (e.g. material
abrading or damages) and must not rotate with unbalances.
7) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or
sediments.
We recommend a frequent cleaning of the device. Please use a moist, lint-free cloth. Never use alcohol or
solvents!
Maintain proper lubrication on the winch. Do not allow oil or grease on braking surfaces.
Do not use any type of lubrication on the column surfaces.
Do not grease or lubricate the brake mechanism of the winch!
Keep the pulleys, the cable, the tower sections and all rubbing parts well greased!
Maintenance and service operations are only to be carried out by authorized dealers.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.
