The selected transmission channel is indicated by the status indicator.
Channel
Color
1
Red
2
Green
3
Blue
4
Yellow (red/green)
5
Cyan (green/blue)
6
Magenta (red/blue)
Thus, the wireless DMX network is set up and the receivers are paired to the transmitter. The assignment of
the receivers to the transmitter is kept memorized even after disconnecting the power supply.
As soon as the transmitter receives a DMX signal, the status indicator switches to red. Shortly afterward, the
status indicators of the receivers start flashing green to indicate that the DMX signal is being received. The
DMX-controlled units can now be controlled via radio.
After the operation, disconnect the power supply cable from the mains outlet, to prevent unnecessary power
consumption.
USE
Several receivers may be assigned to a transmitter. It is possible to operate a maximum of 512 receivers.
Transmission 1:1
The DMX signal is fed to a transmitter which sends it
via RF. A receiver with the same transmission
channel receives the RF signal and distributes it as
a DMX signal.
Transmission 1: Many
The DMX signal is fed to a transmitter which sends it
via RF. Several receivers with the same
transmission channel receive the RF signal and
distribute it as a DMX signal.
Parallel Transmission
It is possible to operate 6 wireless DMX networks
with 6 transmitters in parallel without mutual
interference by adjusting them to different
transmission channels. The wireless DMX networks
operate independent of each other in 1:1 or 1: many
transmission modes.
28/40
00128199, Version 1.0
