Maintenance - Protool PDP 18-2 E-1 Originalbetriebsanleitung

onto the spanner surface (2) of the drill spindle
and hold tight. Loosen the drill chuck with a light
blow on the Allen key.
Screw on the drill chuck in reverse order.
Before tightening the securing screw (20)
respectively, the quick clamping drill chuck
must be tightened securely (tightening
torque approx. 30 Nm).
Screwdriving (Fig.)
The drill spindle (15) is equipped with an internal
hexagon for use with screwdriver bits (13). After
removing the drill chuck, a screwdriver bit can
be inserted directly into the internal hexagon
of the drill spindle. Slide the safety cover (14)
onto the spindle thread first, as it will retain the
screwdriver bit.
Operational Tips
Sharpening drill bits
Only HSS drill bits in perfect condition
(HSS = high speedsteel) should be used for
drilling metal.
Bench Stands
For jobs requiring high precision, the use of a
bench stand (accessories) is recommended.
Machine vice
Clamp work pieces tight for drilling, i.e., using
the machine vice (see Accessories). This keeps
the work piece from turning and thus prevents
resulting accidents.
Drilling tiles
Set selector switch (4) to the drill symbol. Wait
until the tile has been completely penetrated
before switching over to the hammer symbol and
continuing with percussion drilling.
Tapping
Clamp the tap drill carefully and very tight to
prevent slipping.
Storage
The unit should be stored in a dry place where it
is protecte against freezing.
Service
See enclosed sheet.

Maintenance

‰ Periodically clean the ventilation slots (5) on
the motor housing.
‰ When the carbon brushes are worn out, the
machine switches itself off. The machine
must then be sent to customer service for
maintenance (see enclosed sheet).
‰ Cable may only be replaced by a specialised
electronics workshop qualified to perform
such work.
‰ After an operating period of approx.
200 hours, the following maintenance work
must be performed:
‑ Renew the grease filling of the gearbox.
To verify that the double insulation is
intact, the machine must be subjected to
a safety test after‑wards. Therefore, these
maintenance tasks are to be performed
only by a professional electro‑workshop.
Environmental Protection/
Dissposal
Power tools, accessories and packaging should
be sorted for environmental‑friendly recycling.
Only for EC countries:
Do not dispose of power tools into
household waste!
According to the European Directive 2002/96/
EC on waste electrical and electronic equipment
and its incorporation into national law, power
tools that are no longer suitable for use must be
separately collected and sent for recovery in an
environmental‑friendly manner.
REACh
REACh is a European Chemical Directive
that came into effect in 2007. As "downstream
users" and product manufacturers, we are
aware of our duty to provide our customers
with information. We have set up the following
website to keep you updated with all the latest
news and provide you with information on all
the materials used in our existing products:
http://www.tts‑protool.com/reach
Guarantee
Our equipment is under warranty for at least
12 months with regard to material or production
faults in accordance with national legislation.
In the EU countries, the warranty period for
exclusively private use is 24 months (an invoice
or delivery note is required as proof of purchase).
Damage resulting from, in particular, normal
wear and tear, overloading, improper handling,
13
