Tool Specifications; Operating Controls - Protool PDP 18-2 E-1 Originalbetriebsanleitung

Tool Specifications

Original instruction
Supply voltage [V]
Mains frequency [Hz]
Nom. power requirement [W]
Rated rpm [min ]
‑1
1st speed
2nd speed
Rated rpm (no load) [min
1st speed
2nd speed
Pulse frequency [min
1st speed
2nd speed
Speed selection
Speed selection
Drill chuck capacity range [mm]
Drill chuck capacity range
Bit holder, hexagonal socket
Drill dia. [mm] s teel
aluminium
wood
concrete
Clamping collar dia. [mm] 43
Weight [kg]
Protection class

Operating controls

1 Key‑type drill chuck
2 Spanner surface
3 Auxiliary handle collar
4 Drill/Percussion drill switch
5 Ventilation slots
6 Depth stop
7 Auxiliary handle
8 Gear selector switch
9 Rotational direction switch
1 0 Speed selector thumbwheel
1 1 ON/OFF switch
12 Lock‑on button
13 Screwdriver attachment
14 Safety cover
15 Drill spindle
16 Chuck key
17 Open‑ended spanner
18 Allen key
19 Keyless chuck
20 Securing screw
Not all of the accessories illustrated or described
are included as standard delivery.
10
]
‑1
]
‑1
Impact Drill
PDP 18-2 E-1
230‑240
50/60
650
0 ... 600
0 ... 1730
0 ... 1100
0 ... 3000
0 ... 12 600
0 ... 34 600
•
•
1.5 ... 13
1/2" ‑ 20 UNF
1/4"
13
16
35
16
43
1.8
ll /
Symbols used in the manual and
on the machine
Not to be included in municipal
refuse.
Double insulation.
This symbol is used to mark safety
instructions that must be observed to
prevent damage to persons.
Read the instructions
GB
