Operational Tips
Sharpening drill bits
Only HSS drill bits in perfect condition
(HSS = high speedsteel) should be used for
drilling metal.
Bench Stands
For jobs requiring high precision, the use of a
bench stand (accessories) is recommended.
Machine vice
Clamp work pieces tight for drilling, i.e., using
the machine vice (see Accessories). This keeps
the work piece from turning and thus prevents
resulting accidents.
Drilling tiles
Set selector switch (12) to the drill symbol. Wait
until the tile has been completely penetrated
before switching over to the hammer symbol and
continuing with percussion drilling.
Storage
The unit should be stored in a dry place where it
is protecte against freezing.
Service
See enclosed sheet.

Maintenance

‰ The ventilation slots (10) on the motor casing
should be cleaned out from time to time.
‰ After approx. 100 hours of operation, check
the motor brushes and replace if necessary.
Clean the motor housing.
‰ After approx. 200 hours of operation, renew
the grease filling in the gearbox.
To verify that the protective insulation
remains intact, the machine must be
subjected to a technical safety test
afterwards. For this reason, this work must
be performed exclusively by a professional
electro‑workshop.
12
Environmental Protection/
Dissposal
Power tools, accessories and packaging should
be sorted for environmental‑friendly recycling.
Only for EC countries:
Do not dispose of power tools into
household waste!
According to the European Directive 2002/96/EC
on waste electrical and electronic equipment
and its incorporation into national law, power
tools that are no longer suitable for use must be
separately collected and sent for recovery in an
environmental‑friendly manner.
REACh
REACh is a European Chemical Directive
that came into effect in 2007. As "downstream
users" and product manufacturers, we are
aware of our duty to provide our customers
with information. We have set up the following
website to keep you updated with all the latest
news and provide you with information on all
the materials used in our existing products:
http://www.tts‑protool.com/reach
Guarantee
Our equipment is under warranty for at least
12 months with regard to material or production
faults in accordance with national legislation.
In the EU countries, the warranty period for
exclusively private use is 24 months (an invoice
or delivery note is required as proof of purchase).
Damage resulting from, in particular, normal
wear and tear, overloading, improper handling,
or caused by the user or other damage caused
by not following the operating instructions, or any
fault acknowledged at the time of purchase, is
not covered by the warranty.
Complaints will only be acknowledged if the
equipment has not been dismantled before being
sent back to the suppliers or to an authorised
PROTOOL customer support workshop. Store
the operating instructions, safety notes, spare
parts list and proof of purchase in a safe place.
In addition, the manufacturer's current warranty
conditions apply.
Note
We reserve the right to make changes to the
technical data contained in this information as
a result of ongoing research and development
work.
