1. Introduction

MANUFACTURER:
scheppach
Fabrikation von Holzbearbeitungsmaschine GmbH
Günzburger Straße 69
89335 Ichenhausen / Germany
DEAR CUSTOMER,
We hope your new tool brings you much enjoyment and
success.
NOTE:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability for
damages to the product or damages caused by the prod-
uct that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service tech-
nicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified,
• A breakdown of the electrical system that occurs due
to the non-compliance of the electric regulations and
VDE regulations 0100, DIN 57113 / VDE0113.
WE RECOMMEND:
Read through the complete text in the operating instruc-
tions before installing and commissioning the device. The
operating instructions are intended to help the user to
become familiar with the machine and take advantage of
its application possibilities in accordance with the recom-
mendations. The operating instructions contain important
information on how to operate the machine safely, pro-
fessionally and economically, how to avoid danger, costly
repairs, reduce downtimes and how to increase reliability
and service life of the machine.
In addition to the safety regulations in the operating in-
structions, you have to meet the applicable regulations
that apply for the operation of the machine in your coun-
try. Keep the operating instructions package with the ma-
chine at all times and store it in a plastic cover to protect it
from dirt and moisture. Read the instruction manual each
time before operating the machine and carefully follow its
information. The machine can only be operated by per-
sons who were instructed concerning the operation of the
machine and who are informed about the associated dan-
gers. The minimum age requirement must be complied
with.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
2.

Layout (Fig. 1)

1. Motor drive unit
2. Pole saw
3. Hedge trimmer
4. Power scythe
5. Grastrimmer
6. Front handle
7. Safety switch
8. Start switch
9. Charger
10. Battery pack 2x
11. -
12. Automatic oil pump
13. Saw chain
14. Chain saw blade
15. Cutting unit
16. Adjustment lever
17. Cutting blade
18. Protection shield (power scythe + grassrimme
19. -
20. Hexagon wrench, size 19/13
21. Allen key (size 4)
22. Allen key (size 5)
23. Belt
3.

Scope of delivery

Open the packaging and take out the equipment
•
with care.
Remove the packaging material and any packaging
•
and/or transportation braces (if available).
Check to see if all items are present.
•
Inspect the equipment and accessories for trans-
•
port damage. In case of complaints the supplier is
to be informed immediately. Complaints received
at a later date will not be acknow ledged.
If possible, keep the packaging until the end of the
•
guarantee period.
Read the operating instructions to make your-
•
self familiar with the device prior to using it.
After that, please dispose of it in an environmental-
ly friendly way.
Only use original parts for accessories as well as
•
for wearing and spare parts. Spare parts are avail-
able from your specialized dealer.
Specify our part numbers as well as the type and
•
year of construction of the device in your orders.
m Important!
The equipment and packaging material are not toys.
Do not let children play with plastic bags, foils or
small parts. There is a danger of swallowing or suff
ocating!
