1. Introduction

MANUFACTURER:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
DEAR CUSTOMER,
We hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by the
product that occurs due to:
• Improper handling
• Non-compliance of the operating instructions
• Repairs by third parties, not by authorized service
technicians
• Installation and replacement of non-original spare
parts
• Application other than specified
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regu-
lations and VDE regulations 0100, DIN 57113 /
VDE0113
We recommend:
Read through the complete text in the operating in-
structions before installing and commissioning the
device.
The operating instructions are intended to help the
user to become familiar with the machine and take
advantage of its application possibilities in accord-
ance with the recommendations.
The operating instructions contain important informa-
tion on how to operate the machine safely, profes-
sionally and economically, how to avoid danger, cost-
ly repairs, reduce downtimes and how to increase
reliability and service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regu-
lations that apply for the operation of the machine in
your country.
Keep the operating instructions package with the
machine at all times and store it in a plastic cover to
protect it from dirt and moisture. Read the instruction
manual each time before operating the machine and
carefully follow its information.
The machine can only be operated by persons who
were instructed concerning the operation of the ma-
chine and who are informed about the associated
dangers. The minimum age requirement must be
complied with.
In addition to the safety instructions contained in this
operating manual and the specific regulations of your
16 | GB
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
country, the technical rules generally accepted for the
operation of machines of the same type must be ob-
served.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.

2. Device description

1. Sifter drive, attached
2. Frame arm, right
3. Frame arm, left
4. Frame struts
5. Gusset plate with clamp
6. Gusset plates
7. Frame wall
8. Support feet
9. Wheel ø 160
10. sifter drum insert, grid 10 mm

3. Scope of delivery

• 1 piece Sifter drive, attached (1)
• 1 piece Frame arm, right (2)
• 1 piece Frame arm, left (3)
• 2 piece Frame struts (4)
• 1 piece Gusset plate with clamp (5)
• 3 piece Gusset plates (6)
• 1 piece Frame wall (7)
• 2 piece Support feet (8)
• 2 piece Wheels ø 160 (9)
• 1 piece sifter drum insert, grid 10 mm (10)
• 1 piece transport bow (11)
• Operating instructions
• 1 piece Accessory pack
- 2 piece spacer pins (a)
- 24 piece serrated lock washers ø8,2 (b)
- 22 piece hexagon nuts M8 (c)
- 1 piece hexagon bolt M10x70 (d)
- 3 piece small washer ø10 (e)
- 5 piece hexagon nut M10 (f)
- 14 piece hexagon bolt M8x65 (g)
- 8 piece washers ø8 (h)
- 4 piece hexagon bolt M8x45 (i)
- 2 piece cheese-head screw each M10x95 (j)
- 2 piece bush each (k)
- 2 piece hexagon bolt M8x70 (l)

4. Intended use

The roller sieve has been designed for sieving com-
post, gar den soil, cloddy sand, or mixing different
kinds of soil.
The equipment is allowed to be used only for its pre-
scribed purpose. Any other use is deemed to be a
case of misuse.
