EN
A A
A 2 x Hex Bolt M8x65
B 2 x Hex Bolt M8x50
C 2 x Hex Bolt M8x40
D 4 x Hex Bolt M6x40
E 1 x Hex Bolt M8x20
F 1 x Hex Bolt M8x16
G 8 x Nylon Lock Nut M8
H 6 x Nylon Lock Nut M6
I 2 x Hex Bolt M6x12
J 1 x Big Flat Washer Ø8
26
B C D
N
J
Y
E F
I
O
L
Z
K 1 x Angle Bracket
L 1 x Adjustable Pole Spacer
M 2 x Hitch Spacer
N 5 x R Pin Ø3
O 4 x R Pin Ø2
P 2 x Clevis Pin Ø9.5x25
Q 4 x Clevis Pin Ø6x37
R 2 x Clevis Pin Ø8x59.5
Y 1 x Hitch Pin
Z 4 x Plastic Plug
G H
P
Q
R
M
K
