Technical Data; Included Items; Spare Parts; Safety Advice - Parkside HG06876 Montage-, Bedienungs- Und Sicherheitshinweise

Extra Spare Parts (included) (see fig. M)
Holder for lever handle
8
Seal washer sheet ø16 mm
34
Piston
35
O-ring ø15 mm
36
Collet
37
Aligning buckle
38
O-ring ø18.5 mm
39

Technical data

Container dimensions:
Overall weight,
empty weight:
Filled weight (max. 16 l):
Volume of the total residual: approx. 25 ml
Length of spray tube:
Max. Filling capacity:
Max. permissible
operating pressure
(including the entire
nozzle , , ,
23 24 25 26
Average flow rate of
different nozzles at
common working
pressure of 3 bar:
Size of nozzles:
Size of filter inside
spray tube handle :
19
Size of filter screen :
31
approx. 350 x 184 x
490 mm (W x L x H)
approx. 3.2 kg
approx. 19.2 kg
approx. 1300 mm
approx. 16 l
): approx. 2–4 bar
0.85 l / min (Conical
nozzle )
23
0.90 l / min (Fan
nozzle )
24
1.40 l / min (Double
conical nozzle
25
1.20 l / min (Four-
hole nozzle )
26
ø 1.77 mm
(Conical nozzle
1.4 x 0.7 mm
(Fan nozzle )
24
ø 1.77 mm (Double
conical nozzle
25
ø 1 mm (Four-hole
nozzle )
26
ø 0.7 mm
ø 1.1‒1.8 mm
Pressure regulating
value :
22
Operating
temperature:
Carrying method:

Included items

1 Garden pressure
sprayer
1 Spray tube
1 Pair of carrying belts

Spare parts:

1 Piston
4 Seal washer sheet
ø 16mm
2 O-ring ø15 mm
2 O-ring ø18.5mm

Safety advice

General safety advice

) KEEP ALL THE SAFETY ADVICE AND INSTRUC-
TIONS IN A SAFE PLACE FOR FUTURE REFER-
ENCE!
) C hildren or persons who lack the knowledge
23
or experience to use the device or whose
physical, sensory or intellectual capacities are
limited must never be allowed to use the device
) without supervision or instruction by a person
responsible for their safety. Children must
never be allowed to play with the device.
W arehousing of pesticide. It shall be kept out
of reach of children. Disposal of pesticide shall
follow the safety instructions furnished its man-
ufacturer
1.4 ± 0.2 bar
(Open pressure)
1 ± 0.15 bar (Close
pressure)
0–40 °C
At the operator's
back, using the car-
rying belts
30
1 Hose
1 Assembly, operating
and safety instructions
2 Collets
1 Aligning buckle
1 Holder for lever
handle
GB 7
