FAD correction of capacity for altitude
Capacity given in the form of FAD („Free Air Delivery") applies to the following conditions:
Altitude
Atmospheric pressure
To calculate FAD compressor capacity in dependence on altitude, it is necessary to apply correction
factor according to the following table:
Altitude [m.n.m.]
FAD correction factor
NP-DK50 2x4VR 110-AD-A-1_09-2020
0 m.n.m.
101325 Pa
0 -1500
1
18
Temperature
Relative humidity
1501 - 2500 2501 - 3500
0.80
TECHNICAL DATA
20°C
0%
3501 - 4500
0.71 0.60
